M12 Circular Connectors

ULO-CC03-M12X-XXP-FF-SPSH-SH00X

ULO-CC03-M12X-XXP-FF-SPSH-SH00X M12 sensor/actuator female socket designed for reliable circular connector wiring, featuring pin options A Coding:3/4/5/6/8/12Pin B Coding:5 Pin D Coding:4 Pin, rated current 1.5A(A Coding:12Pin)，2A(A Coding:6/8Pin)，4A(A Coding:3/4/5Pin，B Coding:5Pin，D Coding:4Pin), rated voltage 30V(A Coding:6/812Pin)，60V(A Coding:5Pin，B Coding:5Pin)，250V(A Coding:3/4 Pin，D Coding:4Pin), protection level IP67.

Coding

A-Coded, B-Coded, D-Coded

Number of potentials

03,04,05,06,08,12 Pin

Rated current

4A max.

Rated voltage

250V max.

Quick Check

M12 Circular Connector

Industrial Field Connection

Designed for sensor, actuator, data and power transmission

Multiple Coding Options

Supports different coding types for signal, data and power applications

Rugged IP67 Design

Reliable circular connector solution for demanding industrial environments

Datasheet

Product Overview

The ULO-CC03-M12X-XXP-FF-SPSH-SH00X is a sensor/actuator female socket for M-series circular connector applications. Key specifications include Number of potentials: A Coding:3/4/5/6/8/12Pin B Coding:5 Pin D Coding:4 Pin, Rated current: 1.5A(A Coding:12Pin)，2A(A Coding:6/8Pin)，4A(A Coding:3/4/5Pin，B Coding:5Pin，D Coding:4Pin), Rated voltage: 30V(A Coding:6/812Pin)，60V(A Coding:5Pin，B Coding:5Pin)，250V(A Coding:3/4 Pin，D Coding:4Pin), Protection level: IP67. Product design details include Contact material: CuZn, Contact surface: Au, Contact carrier material: PA, Sealing material: Silicon, Flammability rating: UL94V-0. Use it for compact sensor, actuator and industrial field wiring where a secure circular connection is required.

Product Family

Key Features

Versatile M12 Connection

Designed for signal, data, and power transmission in industrial automation and field device applications.

Reliable Field Protection

Sealed connector structure supports reliable protection up to IP67 / IP68 when locked, helping ensure stable operation in harsh environments.

Multiple Coding & Connection Options

Available with different coding options to prevent mismating, with male/female, straight/angled, shielded/unshielded, cable, panel mount, and field assembly versions.

Typical Applications

Industrial Sensor & Actuator Wiring

Ideal for connecting sensors, actuators, valves, switches, and field devices in automation systems.

Data & Communication Networks

Suitable for industrial data transmission, Ethernet communication, and distributed control system connections.

Power & Signal Interfaces

Used for reliable power and signal connection in controllers, I/O modules, drives, instruments, and machine equipment.

Harsh Industrial Environments

Supports stable connection in production lines, machinery, outdoor equipment, and applications with vibration, shock, moisture, or electromagnetic interference.
