ULO-TB11-350R/3.5
Compact wire protector terminal block for PCB and equipment wiring where conductors need screw clamping with wire protection, featuring 3.5 mm pitch, 10A/130V, screw connection.
Certifications
Core Applications
ULO-TB11-350R/3.5
Compact wire protector terminal block for PCB and equipment wiring where conductors need screw clamping with wire protection, featuring 3.5 mm pitch, 10A/130V, screw connection.
Product Overview
The ULO-TB11-350R/3.5 is a 3.5 mm wire protector terminal block designed for PCB and equipment wiring where conductors need screw clamping with wire protection. Key specifications include 3.5 mm pitch, 10A rated current, 130V rated voltage, screw connection, available in 2 to 24 positions. Product design details include PA66 insulation, UL94V-0 flammability rating, default green housing color.
Product Family
Key Features
Wire Protector Clamp Design
Integrated wire protector structure helps prevent conductor damage during screw tightening and ensures stable wire retention.
Multiple Wiring Directions
Available with horizontal, vertical, and angled wiring options to meet different PCB layout and installation requirements.
Flexible Pitch & Pole Options
Supports a wide range of pitches, pole numbers, and connection styles for signal and power connection in electronic devices.
Typical Applications
Security Systems
Suitable for wiring interfaces in access control, alarm systems, monitoring devices, and security control boards.
Lighting Equipment
Used for power and signal connection in LED drivers, lighting controllers, and lighting system modules.
General Electronic Devices
Ideal for PCB wire connection in controllers, instruments, power modules, and small electronic equipment.
Industrial Control Boards
Provides reliable board-level wiring for control panels, automation devices, and industrial electronic systems.
