ULO-TB38-245/7.5
Compact spring clamp PCB terminal block for fast PCB wiring with spring clamp termination and compact board mounting, featuring 7.5 mm pitch, 17A/750V, spring-cage connection.
Certifications
Core Applications
ULO-TB38-245/7.5
Compact spring clamp PCB terminal block for fast PCB wiring with spring clamp termination and compact board mounting, featuring 7.5 mm pitch, 17A/750V, spring-cage connection.
Product Overview
The ULO-TB38-245/7.5 is a 7.5 mm spring clamp PCB terminal block designed for fast PCB wiring with spring clamp termination and compact board mounting. Key specifications include 7.5 mm pitch, 17A rated current, 750V rated voltage, spring-cage connection, available in 2 to 24 positions. Product design details include PA66 insulation, UL94V-0 flammability rating, default green housing color.
Product Family
Key Features
Spring Clamp Connection
Spring clamp technology provides fast, secure, and vibration-resistant wire connection without frequent retightening.
Maintenance-Free Wiring
Stable clamping force helps maintain reliable contact over time, reducing maintenance work in long-term applications.
Flexible PCB Layout Options
Available in multiple pitches, wiring directions, and single- or multi-layer designs to meet different PCB connection needs.
Typical Applications
Communication Equipment
Ideal for signal and power wiring in communication devices, control interfaces, and electronic modules.
Lighting Systems
Suitable for LED drivers, lighting controllers, and power distribution interfaces in lighting equipment.
Security & Alarm Systems
Used in access control, alarm panels, monitoring devices, and security control boards.
Building & Industrial Wiring
Supports reliable PCB-level wiring in building automation, control panels, instruments, and industrial electronic systems.
